Leaching Agitation Tank
EPIC is one of professional China Leaching Agitation Tank manufacturer and supplier, if you are looking for the Leaching Agitation Tank, consult us now!
Send Inquiry
Product Description
EPIC is one of leading China Leaching Agitation Tank manufacturer, supplier and exporters. This machine features a reasonable and compact structure,and high transmission efficiency.Twin impellers is used which has bigger diameter,lower turning speed,lower agitation power consumption,and lower wear of the carbon. Airis sent to the bottom via pipes,so that it is evenly spared with less bubble.It gives moderate agitating strength,to keep the slurry density and fineness to be basically uniform in the tank,so as to improve leaching ability of the cyanidation and the absorption intensity.We improved the charge system and transmission system of leaching (adsorption)tank.
Product Parameter
| Model |
denmision of tank (mm) |
Effective capability (m³) |
Impeller speed (r/min) |
Density (%) |
power (kw) |
Weight (kg) |
| SJ1.5×1.5 | φ1.5×1.5 | 2.25 | 28 | <45 | 18.5 | 2210 |
| SJ2×2.5 | φ2×2.5 | 6 | 72 | <45 | 2.2 | 2800 |
| SJ2.5×3.15 | φ2.5×3.15 | 13 | 57 | <45 | 2.2 | 3370 |
| SJ3×3.15 | φ3×3.15 | 19 | 43 | <45 | 4 | 5630 |
| SJJ3×3.5 | φ3×3.5 | 23 | 43 | <45 | 4 | 5600 |
| SJ3.15×3.55 | φ3.15×3.55 | 21 | 40.85 | <45 | 4 | 5800 |
| SJ3.5×3.5 | φ3.5×3.5 | 30 | 52 | <45 | 5.5 | 5700 |
| SJ3.55×4 | φ3.55×4 | 34 | 36.3 | <45 | 4 | 6650 |
| SJ4×4 | φ4×4 | 48 | 45.71 | <45 | 5.5 | 7340 |
| SJ4×4.5 | φ4×4.5 | 48 | 31.5 | <45 | 5.5 | 8290 |
| SJ4.5×5 | φ4.5×5 | 72 | 31 | <45 | 7.5 | 10800 |
| SJ5×5.6 | φ5×5.6 | 98 | 27.2 | <45 | 7.5 | 11430 |
| SJ5.5×6 | φ5.5×6 | 112 | 31 | <45 | 7.5 | 14290 |
| SJ6×6.5 | φ6×6.5 | 170 | 23 | <45 | 18.5 | 18000 |
| SJ6.5×7 | φ6.5×7 | 215 | 23 | <45 | 18.5 | 29030 |
| SJ7×7.5 | φ7×7.5 | 269 | 21 | <45 | 22 | 32800 |
| SJ7.5×8 | φ7.5×8 | 331 | 21 | <45 | 22 | 42800 |
| SJ8×8.5 | φ8×8.5 | 342 | 16.4 | <45 | 22 | 42470 |
| SJ8.5×9 | φ8.5×9 | 480 | 17 | <45 | 22 | 46620 |
| SJ9×9.5 | φ9×9.5 | 572 | 17 | <45 | 30 | 53000 |
| SJ9.5×10 | φ9.5×10 | 673 | 14 | <45 | 30 | 58000 |
| SJ10×10.5 | φ10×10.5 | 785 | 14 | <45 | 30 | 64000 |
| SJ11×12 | φ11×12 | 1140 | 13 | <45 | 55 | 73000 |
| SJ12×13 | φ12×13 | 1470 | 13 | <45 | 75 | 86000 |
